16-Port 10/100Base-TX Fast Ethernet Switch


Backbone Switch

With up to 3.2Gbps switching fabric, the FNSW-1601 can provide high bandwidth connectivity to Fast Ethernet network backbone or can be the backbone of your workgroup.

Department Switch

Uplink directly by any straight or crossover cable to the backbone switch, the FNSW-1601 provides the connectivity to back plane yet segment the network traffic of the department to your backbone.

FNSW 1601v9 4

Hardware Specifications
Hardware Version V9
10/100BASE-TX MDI/MDIX Ports 16
Throughput (packet per second) 2.38Mpps
Switch Fabric 3.2Gbps
Weight 1.3kg
Power Consumption/Dissipation 1.3 watts / 4.4BTU
Power Requirements 100~240V AC, 0.2A, 50-60Hz
Dimensions (W x D x H) 440 x 140 x 44mm, 1U height
Switch Processing Scheme Store-and-Forward
Address Table 8K entries
Maximum Packet Size 1522bytes
Flow Control Back pressure for half duplex
IEEE 802.3x pause frame for full duplex
DIP Switch Operation mode selection
■ Standard
■ Flow control off
■ Extend
Standards Conformance
Regulatory Compliance FCC Part 15 Class A, CE
Standards Compliance IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3x (Full-Duplex Flow Control)
IEEE 802.3az Energy Efficient Ethernet (EEE)
Temperature Operating: 0~50 degrees C
Storage: -10~70 degrees C
Humidity Operating: 5% to 95% (non-condensing)
Storage: 5% to 95% (non-condensing)
